M1 1325 CNC Centre Router
M1 1530 CNC Centre Router
M1 2030 CNC Centre Router
Features of the M1 CNC Centre Router
Vacuum Table – Air-Cooled & Hassle-Free
- Secure hold – Keeps boards in place with vacuum suction.
- No clamping needed – Speeds up setup and saves time.
- Air-cooled pump – No refilling or winter prep needed.
- Low maintenance – Reliable and easy to manage daily.
9kW HQD Spindle – Solid, Quiet, Affordable
- High-quality HQD build – Inspired by top Italian brand HSD.
- Air-cooled system – Keeps performance steady without fuss.
- Low noise, high efficiency – Runs smooth even during long jobs.
- Great value – Reliable industrial performance without the price tag.
NK105 G3 Controller – Learn Fast, Work Faster
- Easy to pick up – Most users are up and running in 2 hours.
- Clear interface – Nesting, drilling, engraving made simple.
- More buttons, less clicking – Quick access to key functions.
- Smooth workflow – No confusion, just straight-to-the-job control.
25-Series Rails – Stable Under Pressure
- Built for strength – Rated for 3000kg dynamic load on gantry.
- Solid motion – Handles weight with zero compromise on accuracy.
- No shake, no shift – Keeps everything square, even under stress.
- Overbuilt by design – More support than the machine will ever need.
300mm Z Clearance – Ready for Big Jobs
- Tackle thick materials – Process up to 130mm with ease.
- Welded gantry setup – Gives full 300mm working height.
- Perfect for solid wood – Glulam, oak slabs, or chunky sections.
- Works great with long bits
24-Month Warranty – We've Got Your Back
- Fast support – Most issues sorted in a quick call or message.
- UK-based engineers – On-site help in 24–72 hours if needed.
- Huge stock of spares – 2000 sq ft of parts ready to go.
- Built to last – Most spares gather dust… our machines rarely need them.
Upgradable to ATC
- Supports Auto Tool Changer – Switch tools without stopping the job.
- Save serious time – One board, multiple tools, zero hassle.
- Quick ROI – Extra cost pays itself back in just months.
- Extras included – Chucks and collets come with the setup.
Axis-End Sensors – Safety Built In
- Slows and stops in time – Prevents hard hits at the travel limit.
- Protects the machine – Reduces stress on motors and frame.
- Smart servo control – Knows exactly when to cut power.
- Not found in budget builds – We add it during factory supervision.
Leadshine Servo Motors – Smart & Precise
- True servo system – Feedback loop keeps motion accurate.
- No missed steps – Always knows motor position in real-time.
- Handles tension well – Detects and responds to cutting resistance.
- Better than steppers – Built for demanding CNC work.
Positioning Bars
- Pneumatic stops – Aligns boards to exact X=0, Y=0 point.
- No more guessing – Helps avoid misaligned cuts.
- Essential for double-sided work – Keeps both sides perfectly lined up.
- Quick & repeatable – Saves time with every sheet.
Reinforced Frame – Built Like a Tank
- Rock-solid build – Fully welded and oven stress-relieved.
- Extreme accuracy – Surfaces milled for 0.01mm precision.
- No compromise on quality – Industrial-level alignment and squareness.
Auto Lubrication
- Oil pump built-in – Sends oil to runners and guides automatically.
- Timed intervals – Keeps things moving without operator effort.
- Standard on all M1s – No extra cost, no extra hassle.
- Saves time – No need to stop work for manual oiling.
Dust Extractor Included – No Extra Spend
- Double bag system – Handles dust and chips from day one.
- Included as standard – No need to buy it separately.
- Works straight out the box – Perfect for new setups.
- Free of charge – Keeps costs low when starting out.
VCarve Pro Included – Simple & Powerful
- Free with every M1 – No extra licence fees, ever.
- Made for makers – Designed for joinery, signs, 3D work & more.
- Easy to learn – Most users pick it up in just a couple of hours.
- Loads of support – Tutorials and videos available online anytime.
Technical specification
- Working Surface: 1300mm x 2500mm (1560×3080 and 2060×3080 available)
- Max Working Height: Axis Z 300mm
- Motors: Full Servo Motors with Feedback Loop
- Runners: HIWIN 25 Heavy Duty (designed for 3ton kinetic load)
- Speed: 40 meters / minute
- Software Resolution: 0,01mm
- Positioning Accuracy: Physical 0,05mm
- Spindle: 9kW HQD Air Cooled
- Tools: 12 tools in carousel storage with option for additional drill block consisting of 9 drill sockets.
- Spindle RPM: Up to 24000rpm
- Spindle tool diameter: ER32 1-21mm diameter
- Router Bed: Always as standard vacuum bed with T-slots for clamping
- Vacuum Pump: 7.5kW Air Cooled
- Software: Vcarve Pro included
- Weight: 1.7ton (1530 – 2.2t, 2030 – 2.7t)
- Power Supply Needed: 415v 3 Phase 32amp
- Positioning Bolts in the Table: Yes as standard
Fabertec M1 Build Quality
Parts or solutions we offer with every M1 models
9kW AIR COOLED SPINDLE
From now on you can cut even 22mm ply in one pass. We never use cheap water-cooled spindles
AUTOMATIC LUBRICATION
To save time by automatically lubricating all runners and keeping the machine in top condition.
DELTA INVERTER
Branded USA inverter for spindle to always have a smooth revolution of your tool and work even longer shifts.
FULL SERVO MOTORS
Strong and responsive full servo motors. Running on CATBUS circuit.
VACUUM TABLE
Effortlessly keeping boards on a table with the vacuum. Also, clamp rails prepared for solid woods, non-smooth materials.
COOLANT
For your projects requiring aluminium sheet cutting.
300MM GANTRY HEIGHT
All of our CNC router models have a 300mm gantry clearance giving you more ways to process high materials like solid timber, foam for models, etc.
HIWIN GUIDE RAILS
Hiwin 25 Heavy Duty runners designed for 3ton kinetic load. 5 times more than gantry weight to keep squareness for years to come.
END OF AXIS LIMITERS
As an extra safety, we install sensors to prevent CNC from hitting end buffers in case of operator error.
POSITIONING BOLTS
Always position your board exactly on XY=0 in the homing corner. Never again waste your time trying to align your boards to the XY axis.
Affordable prices to allow you to speed up your workshop processes.
| MODEL | TABLE DIMENSIONS | PRICE |
|---|---|---|
| Fabertec M1 1325 | 1300 x 2500 | €22,500 +VAT |
| Fabertec M1 1530 | 1500 x 3000 | €24,900 +VAT |
| Fabertec M1 2030 | 2000 x 3000 | €27,500 +VAT |
| Fabertec M1 1325 ATC 8 Tools Changer | 1300 x 2500 | €27,500+VAT |
| Fabertec M1 1530 ATC 8 Tools Changer | 1500 x 3000 | €29,900 +VAT |
| Fabertec M1 2030 ATC 8 Tools Changer | 2070 x 3080 | €32,500 +VAT |
| OPTIONS | DETAILS | PRICE |
|---|---|---|
| Vacuum Pump 11kW KVE360 | Recommened for 1530/2030 and for cutting smaller elements | €4,500 +VAT |
Lease Purchase
| MODEL | TOTAL PRICE | 36 MONTHS | 48 MONTHS | 60 MONTHS |
|---|---|---|---|---|
| M1 1325 ATC | €27,500 | €934.05 | €738.97 | €622.94 |
NOTE: VAT should be paid upfront.
Delivery
Our M1 1325 and 1530 machines come with free delivery, installation, and training by our Ireland-based engineers at the client's location.
Model 2030 due to machine size can only be delivered by Hiab lorry which will incur an extra charge of €500.
An additional cost of €500 will apply for custom and export documentation when transporting our CNC routers to Northern Ireland.
The client needs a forklift on site to unload and position in the workshop.
- M1 1325 - Min 3ton with 1600mm long forks.
- M1 1530 3.5ton with 1800mm forks.
- M1 2030 4ton with 2200mm long forks.
Warranty
- 24 Months on-site parts and labour warranty included. Obligatory maintenance is required after the first 12 months to keep the second-year warranty at €750 + travel time (€100/h) + Fuel surcharge (€0.90/m).
- To extend the 3-year warranty, an additional cost of 12% of the machine price + VAT applies. This option is only available with the purchase and is subject to mandatory service performed 12 and 24 months after the initial purchase of the machine.
- 12-month warranty for Vacuum Pump & Dust Extractor.
What is Included in the Package?
Fabertec delivers complimentary installation and training services across Ireland, conducted by our experienced Ireland-based engineers. Also, our comprehensive package includes VCarve Pro, a vacuum pump, with all necessary collets, chucks, tools, and spares. Additionally, we offer a free of charge dust extractor for M1 & M2 Models ensuring you have everything you need for a seamless experience.
